10 6044-2002
Selection of data rate
Turning time (max)
Selections of bits
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
ON
1 2 3 4 5 6 7 8 9
S2 300 bit/s
Data
rate
S2 600 bit/s
S2 1 200 bit/s
S2 2 400 bit/s
S2 4 800 bit/s
S2 9 600 bit/s
S2 19 200 bit/s
S2 38 400 bit/s
3.33 ms
Turning
time
1.67 ms
833 µs
417 µs
208 µs
104 µs
52 µs
26 µs
S2 9
S2 10
S2 11
S2 12
S1 Selection of power supply 115/230 V AC
S2 Selection of data rate
Selection of 2- or 4-wire transmission
Selection of no. of data bits (see table below)
S3 Selection of termination and fail-safe
(see next page)
ON
OFF
S3
1 - 4
ON
OFF
S1 S2
1 - 9
DANGER! DO NOT OPEN CONNECTED UNIT
1 2 3 4 5
V.24/RS-232-C
CONNECTION LINE
CONNECTION
Switch settings
The MA-44 can through different switch settings be adapted to a variety of running
conditions. To set the switches, open the plastic case with e.g. a screw-driver.
