3
3. Supplied Items
(5)
(3)
()
(4)
()
• x Long range IR Bullet Weatherproof camera
• x Installation and Operating Instructions
• x Mounting template
• x Sunshield panel (d) with Fixing screw (a) for
Sunshield panel
• x Easy Bracket
• x 3mm Hex L-wrench ()
• 4x anchors ()
• 4x Wall fixing screws (3)
• 4x Wrench Bolts (4)
• x Video Sub-out cable (5)
4. Part Names
4.1 Front view
(a)
(d)
(b)
(c)
(e)
(f)
(h)
(i)
(g)
(a) Fixing screw for sunshield (x)
(b) IR LED
(c) Window
(d) Bracket foot
(e) Foot mount hole (4x)
(f) Arm assembly
(g) Sunshield panel
(h) Bracket Lock
(i) OSD cover
