PRIVACY
Can be set in Non-Interlock mode only. Fixed as (0,0) in Interlock mode.
Mask Size
w (rr) = B0h (-50h) ~ 50h
h (ss) = C4h (-3Ch) ~ 3Ch
Mask Colour (qq, rr)
Colour
Code (qq, rr)
Non-transparency
Transparency
Black
00h
0h
Gray
Light
Dark
0h
h
0h
h
03h
3h
04h
4h
05h
5h
06h
6h
White
07h
7h
Red
08h
8h
Green
09h
9h
Blue
0Ah
Ah
Cyan
0Bh
Bh
Yellow
0Ch
Ch
Magenta
0Dh
Dh
Mosaic
7Fh
–
Pan/Tilt angle (ppp, qqq)
Range of angle (PAN: -80˚ ~ 80˚, TILT : -90˚ ~ 90˚)
Angle resolution (360 / 4096)
PAN = 0h (0°)
TILT = 0h (0°)
PAN = 800h (±80°)
TILT = 0h (0°)
TILT = 400h (+90°)
TILT = C00h (–90°)
PAN = 400h (+90°)
PAN = C00h (–90°)
PAN Angle
TILT Angle
MASK#: Select mask area number (~6)
MODE: Mask enable or disable (OFF/ON)
MOSAIC TYPE: Mosaic roughness setting (~8)
MOSAIC: Mosaic display (OFF/ON)
COLOR: Select mask colour (~4)
TRANSPARENCY: Select mask transparency level (0~3)
