Specifications – Eneo VKC-13100IR12Z Benutzerhandbuch
Seite 51
5
7. Specifications
Type
VKC-13100IR12Z
Art. No.
200264
Series
eneo Candid BCM
System
day&night
Video standard
CCIR/PAL
Sensor size
/4”
Imager
CCD, Sony Super HAD II (Double Scan)
Active picture elements
976 (H) x 58 (V) pixels
Signal-to-noise ratio
50dB (AGC OFF)
Horizontal resolution
700 TVL
Sensitivity (at 50% video signal)
0.6 Lux, (colour), 0.08Lux (B&W) at F. (measured)
Exposure modes
automatic, indoor use, outdoor use, manual, iris priority, shutter priority
Automatic electronic shutter (ESC) /50 ~/00,000sec.
Manual electronic shutter (MES)
/50 ~/00,000sec.
Low speed shutter
yes, ~5fps.
Automatic gain control (AGC)
ON/OFF switchable
Digital Noise Reduction (DNR)
yes, D NR, 3D NR
Flickerless function
ON/OFF switchable
Mirror function
vertical, horizontal, 80° rotation
White balance
automatic, manual, one push, indoor, outdoor, ATW
Backlight compensation
BLC, ON/OFF switchable, automatic, manual, 9 adjustable zones
Wide Dynamic Range
WDR
IR cut filter
switchable
Video outputs
composite (CVBS)
Lens type
zoom
Focal length
3.8mm - 45.6mm
Aperture range (F)
F.6 - F.7
e-PTZ support
no
Digital zoom
x~3x
Horizontal angle of view
45.6° - 4.0°
Iris control
DC
MOD (Minimum object distance)
0.m
Filter screw size
not available
Illumination
infrared, 40x IR-LEDs 850nm
Illumination range
approx. 60m
