3
Assembly:
1. a) Slide the handlebar grips on until the handlebar end
protrudes approx. 17 mm
b) Attach the bar ends. Please ensure that the clamping
screw faces downwards
c) Tighten both clamping screws on the handlebar grips
slightly so that the handlebar grips can still be moved
d) Tighten the clamping screw on the bar end slightly so
that the bar ends can still be moved.
17 mm
2
Technical data:
Type: Ergonomic Handlebar Grips with Bar End
Service-Centre-No.: 63550 - IAN-No. 58886
Torque: Handlebar Grips: 2 Nm
Bar Ends: 5-7 Nm
Production Date: 2011
Guarantee: 2 years
Material: Clamping ring: Aluminium
Grip: plastic
Please read these instructions carefully
Optimum comfort on the ergonomic handlebar grips is only
guaranteed if the assembly is carried out correctly.
The ergonomic handlebar grips with bar end can only be used on
handlebars with a straight assembly area of at least 155 mm and
a diameter of 22 mm – they cannot be used on handlebars with
extremely thin wall thicknesses (various models in aluminium and
carbon).
Please thoroughly grease the clamping area on the handlebar
before assembly.
The handlebar grips are not intended for use with turning handles.
Distributor & service address:
Internationales-Service-Center
Schönbornstr. 14 . 54295 Trier/Germany
Tel: 0049 (0) 651 43 66 452
E-mail: [email protected]
Stand: 20.12.2010
