Florabest Roof Gutter Cleaner - Handbuch

1 Flat jet adapter
2 Pipe end piece
3 Retainer nut
4 Pipe end, telescopic
5 Shut-off switch
6 Pipe connection
7 Quick coupling connection
8 Garden hose 1.5m, 1/2“
9 Quick coupling adapter
Technical specifications
Gutter cleaner
Max. pressure ...................8 bar / 0,8 MPa
Initial Operation
Screw the pipe end piece (2) onto the te-
lescopic pipe (4).
Screw the flat jet adapter (1) onto the pipe
end piece (2).
With the quick coupling connection (7),
create a water connection to the pipe con-
nection (6).
If necessary, the quick coupling adapter
(9) can be used on the quick coupling
connection (7) for your water connection.
Undo the retainer nut (3) on the pipe (4)
and push the pipe to the desired working
length.
Screw the retainer nut back on.
The shut-off switch (5) can be used as a
short-term water stop.
• Store the equipment in a frost-proof
room.
1
2
3
4
5
6
7 8
9
GB IE
