GB/IE
- 13 -
sons, the equipment is not allowed to be used as
a drive unit for other tools of any kind.
The equipment is allowed to be used only for its
intended purpose. Any other use is deemed to be
a case of misuse. The user/operator and not the
manufacturer will be liable for any damage or
injuries of any kind resulting from such misuse.
5. Technical data
Engine type ...............................................................
........ 2-stroke engine, air-cooled, chrome cylinder
Engine power (max.) .................. 1.35 kW/ 1.8 hp
Displacement ............................................42.7 ccm
Idle engine speed .................................3000 min
-1
Max. engine speed
with blade: .............................................9000 min
-1
with line spool: ......................................8400 min -1
Max. cutting speed
with blade: .............................................6800 min
-1
with line spool: ......................................6300 min -1
Ignition ..................................................... Electronic
Drive ............................................ Centrifugal clutch
Weight (with empty tank) ............................. 7.5 kg
Cutting circle diameter of line ...................... 41 cm
Cutting circle diameter of blade .................. 23 cm
Cutting line length ..........................................8.0 m
Cutting line diameter ..................................2.0 mm
Tank capacity ...................................................0.8 l
Spark plug ..................................Champion RCJ6Y
Fuel consumption at
max. engine power .................................. 0.6 kg/h
Specifi c fuel consumption
at max. engine power ........................446 g/kWh
Sound and vibration
L
pA
sound pressure level ...........................98 dB(A)
K
pA
uncertainty ............................................. 1.5 dB
L
WA
sound power level ...........................110 dB(A)
K
WA
uncertainty ............................................ 1.5 dB
Wear ear-muffs.
The impact of noise can cause damage to hea-
ring.
Operation
Vibration emission value a
h
= 4.1 m/s 2
K uncertainty = 1.5 m/s 2
Keep the noise emissions and vibrations
to a minimum.
•
Only use appliances which are in perfect
working order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appli-
ance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
6. Before starting the
equipment
6.1 Assembly
6.1.1 Fitting the steady grip (Fig. 3a-3c)
Fit the steady grip (3) as shown in Figures 3a-3c.
Do not tighten the screw (20) until you have set
the optimum working position with the carrying
strap (17) (see also section 6.2). The steady grip
should be aligned as shown in Figure 1. To dis-
mantle, proceed in reverse order.
6.1.2 Fitting the long handle (Fig. 4a-4c)
Pass the handle screw (32) through the washer
(34) and into the connecting piece of the long
handle (1). Secure the handle screw loosely
with the nut (33). Now press the locking lever
(A) and push the long handle (Fig. 4a/Item 2)
carefully into the connecting piece for the long
handle. While doing so, ensure that the drive
shafts on the inside of the long handle slide into
each other (turn the line spool (13) / cutting bla-
de (18a/18b) gently if required). The lug of the
locking lever (A) must latch into the hole (B). Now
tighten the handle screw as shown in Figure 4c. To
