Prior to installation / Mounting / Start-up
Prior to installation
Important: The electrical connection must be es-
tablished by a qualified electrician or a person trai-
ned to perform electrical installations. This person
must be familiar with the characteristics of the lumi-
naire and connection regulations.
Familiarise yourself with all instructions and
diagrams in this manual, as well as with the lu-
minaire before installation.
Before installation, ensure that the cable that the
luminaire will be attached to is de-energised. To
do this, remove the fuse or switch off the circuit
breaker in the fuse box (0 position).
Use the voltage tester to verify de-energised status.
Mounting
Mounting the luminaire
Remove the visible screws 2 on the side of the
connection housing 6 and take off the moun-
ting bracket 1 on the rear (see Fig.).
Use the slotted holes intended for the mounting
bracket 1 to mark the bores.
Drill the fastening bores (∅ approx. 6 mm, depth
approx. 40 mm). Ensure that you do not damage
the supply line.
Introduce the dowels into the bores. Fasten the
mounting bracket 1 with the provided screws
(large screw head).
Now connect the connection cable of the lumi-
naire to the mains connection cable 3 via the
terminal block 4 , (see Fig.).
Also ensure that the coloured lines are connec-
ted together.
Connect the protective conductor (green-yellow)
to the earth terminal marked in the connection
housing
6 (see Fig.).
Use the screws 2 to fasten the luminaire to the
mounting bracket 1 .
Bend the lamp arm 7 in the desired direction.
Mark the fastening bores for the ceiling brackets
11 . Ensure that the bores are always between
two spots 8 (see Fig.). This ensures a more
secure hold.
Drill the fastening bores (Ø approx. 6 mm, depth
approx. 40 mm) for the ceiling holders
11 .
Introduce the dowels into the bores. Use the
provided screws to fasten the ceiling holders
11
(small screw head).
Screw the ceiling bracket clips 10 into the ceiling
brackets 11 .
Clamp the lamp arm 7 into the ceiling bracket
clips 10 .
Place the lamp lens 13 carefully over the bulb
socket 12 and fasten it in place by tightening the
threaded ring 14 using the supplied tool 15 .
Use a clean, lint-free cloth to insert a bulb 16 .
Carefully turn the bulb 16 clockwise into the
bulb socket.
Ensure that it is properly seated.
Your luminaire is now ready for operation.
Aligning the luminaire
Only change the alignment of the luminaire
when it is switched off.
Allow the luminaire to cool completely.
Turn the individual spots 8 on the base in the
desired direction. The spots 8 can be turned
approx. 270°, and they can also tilt.
Start-up
Inserting / replacing batteries
Loosen the screw on the battery compartment of
the remote control unit
9 (rear) by unscrewing
it with a Phillips screwdriver in the direction.
Remove the spent battery, if necessary.
Insert a new battery into the battery compartment.
Only use type 23 A, 12 V batteries.
Note: Ensure the correct polarity. This is shown
in the battery compartment.
Close the battery compartment of the remote
control unit
9 (rear) by screwing in the screw
with a Phillips screwdriver in the direction.
Start-up / Maintenance and cleaning / Disposal
