47
Setting up and connecting
SKRI 2000 A1
GB
Installation under a wall cupboard
With the supplied mounting plate 20 you can install the appliance under, for ex-
ample, a wall cupboard. For the installation of the appliance proceed as follows:
Slide the mounting plate ♦ 20 to the rear and remove the mounting plate 20 .
Select a suitable installation location for the appliance (see also the section ♦
Set-up location requirements p. 45).
Hold the mounting plate ♦ 20 under the installation location. Thereby the front
edge of the mounting plate 20 should be approx. 6.8 cm behind the front
of the cupboard so that, after the installation, the appliance is fl ush with the
cupboard. The side edges of the mounting plate
20 must have a spacing of
about 4.5 cm to adjacent cabinets or walls.
NOTICE
If you wish to install the unit fl ush to the left on an adjacent cabinet or a ►
wall, remove the safety clip 22 from the appliance beforehand.
Mark the 4 securing points with a pencil. ♦
Using a spike or nail, make a small depression at the respective marking points. ♦
If wished, insert the supplied spacer ♦ 28 with the retaining lug into the
respective depression on the mounting plate 20 .
Firmly screw the mounting plate ♦ 20 on with the supplied screws (see illustration).
