Phonitor 3 DAC – Manual
2
Getting started
Read the safety instructions starting on page 11.
Make sure that the mains voltage of the Phonitor 3 DAC corresponds to the voltage of your
region and that the fuse has the correct value for the selected voltage (see specifications
on page 8.)
The power switch on the back of the Phonitor 3 DAC must be in the off position. (Off = O /
On = I).
Connect the supplied power cord to the power connector of the Phonitor 3 DAC and to a
power outlet.
If the supplied power cord does not match your mains socket outlet, please contact your dealer.
The devices that are to be connected to the Phonitor 3 DAC must be be switched off.
Connect the outputs of your analog sources to the analog inputs of the Phonitor 3 DAC.
Please use appropriate audio cables (XLR).
Audio cables not included in the scope of delivery.
Connect the outputs of your digital sources (e.g. Mac or PC, CD player) to the digital inputs
of the Phonitor 3 DAC using appropriate digital audio cables (USB, S/PDIF coaxial, S/PDIF
optical, AES/EBU).
Digital audio cables not included in the scope of delivery.
For operation on Windows® computers, please download and install the latest driver from the spl.audio page under the “Driver”
section. Since the USB port is Apple Class 2 compliant, Macs, iPhones and iPads do not require additional drivers.
Connect audio cables between the Phonitor 3 DAC and following amplifiers or active moni-
tors (XLR).
Audio cables not included in the scope of delivery.
Connect headphones to the headphone outputs of the Phonitor 3 DAC.
Warning: Never connect a mono jack to the stereo headphone jack and make sure that the plug is fully inserted,
otherwise a short circuit might damage the amplifiers.
Power on
Switch on the power switch on the rear panel of the Phonitor 3 DAC (On = I).
The VU meters light up.
Power off
Switch off the power switch on the rear panel of the Phonitor 3 DAC (Off = O).
The VU meters no longer light up.
