Phonitor 3 DAC – Manual
8
Analog inputs & outputs; XLR (balanced)
Maximaler Ein- und Ausgangspegel 32.5 dBu
Input impedance (XLR) 22 kΩ
Output impedance (XLR) 75 kΩ
Common mode rejection (1 kHz) -82 dB
Frequency range 10 Hz – 100 kHz
THD + N (0 dBu, 1 kHz) 0.0009 %
Noise (A-weighted) -102 dBu
Crosstalk (1 kHz) -95 dB
Dynamic range 134.5 dB
Digital inputs: DAC768 (optional)
AES/EBU (XLR), PCM sample rate: 44,1/48/88.2/96/176.4/192 kHz
Coaxial SPDIF (Cinch), PCM sample rate: 44,1/48/88.2/96/176.4/192 kHz
Optic SPDIF (Toslink F06), PCM sample rate: 44,1/48/88.2/96/mit Glasfaser < 1m: 176.4/192 kHz
USB (B), PCM sample rate: 44,1/48/88.2/96/176.4/192/352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP), sample rate: 2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz
0 dBfs calibrated to 15 dBu
Standard Headphones Output, 6.35 mm (1/4 ″ ) TRS Jack
Wiring Spitze = links, Ring = rechts, Schaft = GND
Source impedance 0.18 Ω
Damping factor (40 Ω) 180
Frequency range 10 Hz – 100 kHz
Crosstalk (1 kHz) -91 dB
THD + N (1 kHz, 0 dBu) 0.0003 %
Noise (A-weighted) -102 dBu
Output power (1 kHz, 1% THD, 250 Ω) 2 x 5 W
Output power (1 kHz, 1% THD, 32 Ω) 2 x 1 W
Dynamic range 134.5 dB
Specifications
