Burkert Type 8643 Benutzerhandbuch
Seite 10
36
Connecting cable:
minimum cross-section: 2.5 mm²
•
maximum length: 0.5 m
•
To ensure that the housing is not leaking, the outer
diameter of the connecting cable must be min.
4 mm for the plastic housing.
actuator terminals
8.4.6.
The Power I/O Box Type 8643 has power-reduced outputs.
This means that the current required to activate the actuator is
provided at the switching moment and reduced to the holding
current after a specified time.
The actuator outputs are designed as ignition protection
type ia.
Terminal designation
Polarity
+
-
Output 1
1
2
Output 2
7
8
Output 3
13
14
Output 4
19
20
english
37
sensor terminals
8.4.7.
The Power I/O Box Type 8643 has eight NAMUR sensor
inputs; two sensors are always assigned to one actuator
output.
The sensors signal back the end positions of a connected
process valve. However, they can also signal back other
process values independently of the actuator outputs (e.g.
operator buttons, scraper end positions).
The sensor inputs are designed as ignition protection type
ia.
Output
Sensor
Terminal designation
Polarity +
Polarity -
1
1.1
3
4
1.2
5
6
2
2.1
9
10
2.2
11
12
3
3.1
15
16
3.2
17
18
4
4.1
21
22
4.2
23
24
english
38
sTarT-uP
9.
safety instructions
9.1.
Warning!
Danger due to improper operation!
Improper operation may result in injuries as well as
damage to the device and the area around it.
Bevore start-up, ensure that the operating personnel
•
are familiar with and completely understand the con-
tents of the operating instructions.
In particular observe the safety instructions and inten-
•
ded use.
The device/the system may be started by adequately
•
trained personnel only.
start-up
9.2.
Before start-up the Power I/O Box Type 8643 with FOUN-
DATION Fieldbus activation, make sure that:
Connection has been properly carried out,
•
that the Power I/O Box has been installed according to
•
the instructions and,
that the Power I/O Box is not damaged.
•
english
39
service
10.
When used in accordance with the instructions given in
this operating manual, the Power I/O Box Type 8643 is
maintenance-free.
Warning!
Hazardous situations can arise during maintenance
work.
Work may only be carried out by authorised specialists
•
who have been trained for working in potentially explo-
sive atmospheres!
Adhere to the regulations applicable in the country of
•
use for the set up / operation of electrical equipment in
potentially explosive atmospheres!
When carrying out maintenance on the device check that:
the lines are seated securely,
→
the plastic housing shows no visible signs of cracks,
→
the seals for the line guides for damage,
→
the operation conforms to regulations.
→
english
Type 8643
