BRONKHORST ®
4.4.6 Verfügbare Parameter
Modbus-Register (im Datenmodell) sind von 1 bis 65536 nummeriert. In einer Modbus-PDU (Protocol Data Unit) sind
diese Register von 0 bis 65535 adressiert. Dieses Modell der Adressierung wird in Abschnitt 4.4 des Dokuments [1]
beschrieben.
In der folgenden Tabelle sind die gebräuchlichsten Parameter aufgelistet.
MODBUS-REGISTER
PARAMETERNAME PARAMETER-
TYP
ZU-
GRIFF
PDU-ADDRESSE REGISTERNUMMER
Bemerkung
Hex Dez. Hex Dez.
Wink Unsigned char W 0x0000 0 0x0001 1 Wert 14592
Initreset Unsigned char RW 0x000A 10 0x000B 11
Valve output Unsigned int RW 0x001F 31 0x0020 32 Bereich 0..32767
Measure Unsigned int R 0x0020 32 0x0021 33
Setpoint Unsigned int RW 0x0021 33 0x0022 34
Setpoint slope Unsigned int RW 0x0022 34 0x0023 35
Analog input Unsigned int R 0x0023 35 0x0024 36
Control mode Unsigned char RW 0x0024 36 0x0025 37
Sensor type Unsigned char RW  0x002E 46 0x002F 47
Capacity unit index Unsigned char RW  0x002F 47 0x0030 48
Fluid number Unsigned char RW 0x0030 48 0x0031 49
Alarm info Unsigned char R 0x0034 52 0x0035 53
Temperature Unsigned int R 0x0427 1063 0x0428 1064 Siehe adr. 0xA138
Alarm limit maximum Unsigned int RW 0x0C21 3105 0x0C22 3106
Alarm limit minimum Unsigned int RW 0x0C22 3106 0x0C23 3107
Alarm mode Unsigned char RW 0x0C23 3107 0x0C24 3108
Alarm setpoint mode Unsigned char RW 0x0C25 3109 0x0C26 3110
Alarm new setpoint Unsigned int RW 0x0C26 3110 0x0C27 3111
Alarm delay Unsigned char RW 0x0C27 3111 0x0C28 3112
Reset alarm enable Unsigned char RW 0x0C29 3113 0x0C2A 3114
Counter value Unsigned int RW 0x0D01 3329 0x0D02 3330 Siehe adr. 0xE808
Counter unit index Unsigned char RW 0x0D02 3330 0x0D03 3331
Counter limit Unsigned int RW 0x0D03 3331 0x0D04 3332 Siehe adr. 0xE818
Counter setpoint mode Unsigned char RW 0x0D05 3333 0x0D06 3334
Counter new setpoint Unsigned int RW 0x0D06 3334 0x0D07 3335
Counter mode Unsigned char RW 0x0D08 3336 0x0D09 3337
Reset counter enable Unsigned char RW 0x0D09 3337 0x0D0A 3338
Identification number Unsigned char RW  0x0E2C 3628 0x0E2D 3629
Normal step c. resp. Unsigned char RW  0x0E45 3653 0x0E46 3654
Stable situation c. resp. Unsigned char RW  0x0E51 3665 0x0E52 3666
Open from zero c. resp. Unsigned char RW  0x0E52 3666 0x0E53 3667
Calibration mode Unsigned char RW  0x0E61 3681 0x0E62 3682
Monitor mode Unsigned char RW  0x0E62 3682 0x0E63 3683
Reset Unsigned char W 0x0E68 3688 0x0E69 3689
Bridge potmeter Unsigned char RW  0x0E85 3717 0x0E86 3718
Modbus slave address Unsigned char RW  0x0FAA 4010 0x0FAB 4011
Polynomial constant A Float RW  0x8128..0x8129 33064..33065 0x8129..0x812A 33065..33066
Polynomial constant B Float RW  0x8130..0x8131 33072..33073 0x8131..0x8132 33073..33074
Polynomial constant C Float RW  0x8138..0x8139 33080..33081 0x8139..0x81A 33081..33082
Polynomial constant D Float RW  0x8140..0x8141 33088..33089 0x8141..0x8142 33089..33090
Sensor differentiator dn Float RW  0x8158..0x8159 33112..33113 0x8159..0x815A 33113..33114
Sensor differentiator up Float RW  0x8160..0x8161 33120..33121 0x8161..0x8162 33121..33122
Capacity Float RW  0x8168..0x8169 33128..33129 0x8169..0x816A 33129..33130
Fluid name String (10 bytes) RW  0x8188..0x818C 33160..33164 0x8189..0x818D 33161..33165
Capacity unit String (7 bytes) RW  0x81F8..0x81FB 33272..33275 0x81F9..0x81FC 33273..33276
Fmeasure Float R 0xA100..0xA101 41216..41217 0xA101..0xA102 41217..41218
FSetpoint Float RW 0xA118..0xA119 41240..41241 0xA119..0xA11A 41241..41242
Temperature Float R 0xA138..0xA139 41272..41273 0xA139..0xA13A 41273..41274 Siehe adr. 0x0427
Capacity 0% Float RW  0xA1B0..0xA1B1 41392..41393 0xA1B1..0xA1B2 41393..41394
Counter value Float RW 0xE808..0xE809 59400..59401 0xE809..0xE80A 59401..59402 Siehe adr. 0x0D01
Counter limit Float RW 0xE818..0xE819 59416..59417 0xE819..0xE81A 59417..59418 Siehe adr. 0x0D03
Counter unit String (4 bytes) R 0xE838..0xE839 59448..59449 0xE839..0xE83A 59449..59450
Device type String (6 bytes) R 0xF108..0xF10A 61704..61706 0xF109..0xF10B 61705..61707
BHTModel number String (14 bytes) RW  0xF110..0xF116 61712..61718 0xF111..0xF117 61713..61719
Serial number String (16 bytes) RW  0xF118..0xF11F 61720..61727 0xF119..0xF120 61721..61728
Customer model String (16 bytes) RW  0xF120..0xF127 61728..61735 0xF121..0xF128 61729..61736
Firmware version String (5 bytes) R 0xF128..0xF12A 61736..61738 0xF129..0xF12B 61737..61739
Seite 19 Modbus interface 9.19.035
