4
4. Installation Instructions
• Make sure the power is removed before the installation.
• Follow the order for applying power.
First connect the low voltage (VDC or 4VAC), then plug the AC adapter to AC outlets to avoid an improper reset
from power jitter and a damage from the surge voltage when no load.
4.1 Mounting the Camera on Wall
) Make the drill holes with using the supplied template.
) Insert the anchors to the drilled holes
3) Match the foot of bracket to the drilled position
4) Fix the bracket by using screws
4.2 Power Supply Connections
Camera can work with either 4VAC or VDC, dual voltage power.
Primary and secondary grounds are completely isolated to avoid the possible ground-loop problems.
Please, refer below picture for power supply and RS-485 connections.
58
58
82
Original size of the
drilling template
see page 39
Clamp connectors of power input:
4VAC / GND (black wire)
4VAC / VDC (red wire)
RS-485+
RS-485–
