6
5.1 MAIN Menu
Select menu item using
Joystick lever , .
Change the values using
Joystick lever , .
NOTE: • Menu items or values with icon also has sub-menus.
To select a sub-menu, select an item with the icon and press of Joystick.
• An item displayed with the --- icon is unable to change values.
5.2 LENS
Set the lens type in accordance with the built-in lens.
NOTE: LENS MUST BE SET TO DC because this camera equips with DC lens.
Function
Descriptions
DC/Video
Selects Auto Iris lens, DC drive type or Video drive type.
BRIGHTNESS (DC, Manual) - Adjusts the video brightness.
IRIS SPEED (DC) - Adjusts the Iris control speed of the DC lens.
FOCUS ADJ (DC, VIDEO) - To adjust the lens focus correctly, activate the Focus Settings mode.
Manual
Selects Manual or Fixed iris lens
BRIGHTNESS - (DC, Manual): Adjusts the video brightness
RETURN
Saves the changes and returns to SETUP menu
NOTE: Video on the monitor may hunt or fluctuate if BRIGHTNESS level is adjusted improperly..
