5.3 EXPOSURE
To enter EXPOSURE menu, press button at MAIN > EXPOSURE.
Function Description
BRIGHTNESS Adjusts the video brightness.
SHUTTER MANUAL - shutter speed manually to specific value between /50(60) ~/0.000.
Set to /50 for PAL and /60 fro NTSC for Auto iris lens.
(Note that this camera equips wit DC auto iris lens.)
A.FLK - Flickerless mode and must be used only at the area where the combination of lighting
frequency and TV system is 50HZ + NTSC or 60Hz + PAL.
ESC - Used with a manual or fixed iris lens. The shutter speed varies linearly along with the object
illuminance. Colour rolling may occur with the fluorescent lighting for NTSC cameras.
NOTE: • When SHUTTER is set to MANUAL or A.FLK mode, SENS-UP will be disabled.
To enable SENSE-UP, SHUTTER must be --- or ESC.
• SHUTTER must NOT be changed from --- for the best performance when LENS is
set to DC.
AGC The higher the gain level, the brighter the screen but the higher the noise.
OFF - Deactivates the AGC function.
LOW - Allows automatic gain control from 5.3dB to 3dB.
HIGH - Allows automatic gain control from 5.3dB to 37dB
SENS-UP At night, camera automatically detects the light level and activates the sense-up.
OFF - Disables the SENS-UP function.
AUTO - Enables the SENSE-UP function. SENSE-UP rate can be limited to x, 4x, 6x, 8x, 0x, x,
6x, 4x, 3x, 64x, 8x, 56x or 5x. The higher SENSE-UP rate can display the brighter
image at lower illumination but motions become slow and white dot noise increases.
RETURN Saves the changes in EXPOSURE menu and returns to MAIN SETUP menu.
