10
Specification of the 1 V
PP
incremental signals
Signal amplitudes A, B (0°, 90°)
0.6 V
PP
to 1.2 V
PP
Signal level for error message
† 0.22 V
PP
Maximum input frequency
400 kHz
Cable length to encoder
Max. 150 m
Specification of the bidirectional EnDat interface
Input component
Differential line receiver (e.g. SN65ALS176D)
Input signals
Differential signals to RS 485
Terminating resistor
121 −
Maximum clock frequency
8000 kHz for EnDat interface
Cable length to encoder
Max. 150 m
EnDat 2.2 Interface
