13 GB/IE/CY
General power tool safety warnings / Start-up Start-up
You can use the prismatic brick 23 to recondition
or regrind the grinding bits. To do so, slowly
bring the grinding bit
20 to the brick 23 with
the tool switched on. Grinding the two abrasive
wheels together will remove uneven areas in the
contour of the grinding bit.
Installing sanding belts
Slide the grinding belt 24 onto the grinding man-
drel 34 from the top. Tighten the screw on the grind-
ing mandrel 34 to secure the grinding belt 24 .
Attaching polishing tools
Screw the polishing tool 22 into the tip of the
mandrel for polishing attachments 25 .
Switching on and off /
Adjusting the speed
Switching on / adjusting the speed:
Set the ON / OFF switch 1 to position „I“ by
pressing down and sliding it forward.
Set the variable speed control 10 to a position
between „1“ and „MAX“.
Switching off:
Set the ON / OFF switch 1 to position „0“.
Information about processing
materials / tool / speed range
Use the router bits to process wood, plastic and
sheetrock at maximum speed.
Determine the speed range for processing zinc,
zinc alloys, aluminium, copper and lead by
testing scrap pieces.
Process plastics and materials with a low melt-
ing point at a low speed.
Process wood at high speeds.
Clean, polish and buff at a medium speed.
Note: The milling bit 27 is not intended for use on
steel or iron. Suitable milling bits are available.
The following information are non-binding recom-
mendations. When performing the actual work also
test yourself, which tools and settings are ideal for
the material you are working on.
Examples of use / selecting the correct tool
Function Accessory Application
Drilling Drill bit 28 Wood applications (see Fig. C)
Milling Milling bit 27 Various applications; e.g. recessing, hollowing
out, shaping, grooving, or making slots
Engraving Engraving bits 26 Marking (see Fig. D)
Polishing, rust
removal
CAUTIoN!
Only apply the tool
to the work piece
under light pressure.
Metal brush 31 Rust removal (see Fig. E)
Polishing tools 22 Processing various metals and plastics, particularly
precious metals such as gold or silver (see Fig. F)
