6 GB/IE/CY
Introduction
Precision Multi-Grinder PFBS 160 A1
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended use
The precision multi-grinder, hereafter also referred
to as tool, is intended for drilling, milling, engrav-
ing, polishing, cleaning, sanding, and cutting
wood, metal, plastic, ceramics or masonry in dry
areas. Any other uses, and / or modifications to the
tool are considered improper use and may result in
serious hazards. Not for commercial applications.
Features
Precision Multi-Grinder:
1 ON / OFF switch
2 Mains lead
3 Metal bracket
4 Louvres
5 Union nut
6 Clamping nut
7 Collet 3.2 mm
8 Spindle lock button
9 Carbon brushes cover
10 Variable speed control
Accessories (see Fig. A):
11 Locking screw
12 Base assembly
13 Flexible shaft
13 b Union nut (Flexible shaft)
14 Collet chuck
15 Stand support
16 Stretch stand
17 Clamp
Accessory kit (42 pieces) (see Fig. B):
18 8 Cutting discs
19 6 Cutting discs
20 5 Grinding bits, abrasive
21 2 Grinding discs, abrasive
22 3 Polishing attachments
23 1 Brick
24 5 Sanding belts
25 1 Clamping mandrel for polishing attachments
26 2 Engraving bits
27 1 Milling bit
28 1 Drill bit
29 1 Clamping mandrel for cut-off / grinding discs
30 2 Plastic brushes
31 1 Metal brush
32 1 Collet 2.4 mm
33 1 Combination wrench
34 1 Sanding belt clamping mandrel
Scope of delivery
1 Precision Multi-Grinder PFBS 160 A1
1 Plastic case
1 Flexible shaft
1 Stretch stand
1 Clamp
1 Base assembly
1 Accessory kit 42 pieces
1 Set of operating instructions
Technical Data
Rated power input: 160 W
Voltage:
230–240 V∼, 50 Hz
Idle speed (n): 10,000–35,000 min -1
Tool holder: max. 3.2 mm
Max. disc ø: 25 mm
Protection class: II /
Introduction / General power tool safety warnings
