Content
Introduction ................................. 4
Intended purpose ......................... 4
General description ...................... 5
Extent of the delivery ........................5
Description of functions .....................5
Overview ........................................5
Technical Data .............................. 5
Notes on safety............................ 6
Symbols and icons ...........................6
General Safety Directions for Power
Tools ...............................................7
Safety Instructions for
Box Column Drills .............................9
Assembly ................................... 10
Operation .................................. 10
Setting up .....................................11
Selecting the speed ........................11
Checking the V-belt ........................11
Tensioning the V-belt .......................12
Adjusting the Drilling Bench.............12
Preselecting the Drilling Depth .........12
Changing the Bit ............................12
Drilling .........................................12
General Information .......................13
Switching on and off ......................13
Clamping the Workpieces ...............13
Removing Blockages .......................13
Cleaning and Servicing............... 14
Cleaning .......................................14
Storage ...................................... 14
Waste disposal and
environmental protection ........... 14
Replacement parts/Accessories .. 15
Troubleshooting ......................... 16
Guarantee ................................. 17
Repair-Service ............................ 18
Service-Center ............................ 18
Importer .................................... 18
Translation of the original
EC declaration of conformity ...... 51
Exploded Drawing ..................... 57
Introduction
Congratulations on the purchase of your
new device. With it, you have chosen a
high quality product.
During production, this equipment has
been checked for quality and subjected
to a final inspection. The functionality of
your equipment is therefore guaranteed. It
cannot be ruled out that residual quantities
of water or lubricants will remain on or in
the equipment/hose lines in isolated cases.
This is not a fault or defect and it repre-
sents no cause for concern.
The operating instructions constitute part of
this product. They contain important infor-
mation on safety, use and disposal.
Before using the product, familiarise your-
self with all of the operating and safety
instructions. Use the product only as de-
scribed and for the applications specified.
Keep this manual safely and in the event
that the product is passed on, hand over
all documents to the third party .
Intended purpose
The bench drill is designed for drilling in
metal, wood, plastic and tiles. Straight
shank drills with a drilling diameter from 3
mm to 16 mm can be used.
The device is intended to be used by do-it-
yourselfers. It was not designed for heavy
commercial use.
The tool is not to be used by persons.
under the age of 16. Children over the
age of 16 may use the tool except under
supervision.
The manufacturer is not liable for damage
caused by an improper use or incorrect
operation of this device.
