General description
See the front fold-out page for
illustrations.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete. Dispose of the pa-
ckaging material correctly.
- Baseplate
- Drilling bench
- Column tube
- Motor unit
- 3 drill lifting arms
- Safety device
- Depth stop
- Drill chuck
- Drill chuck key
- Allen key
- Vice
- Mounting material
- Translation of the original
instructions for use
Description of functions
Please refer to the descriptions below for
information about the operating devices.
Overview
1 Off switch
2 On switch
3 Depth stop with scale
4 Drill chuck
5 Emergency stop switch
6 Drill spindle
7 Safety device
8 Gear cover
9 Hand spindle guide with
3 drill lifting arms
10 Holder for drill chuck key
11 Locking screw for gear cover
12 Clamping screws
13 Retaining screws
14 Motor unit
15 Column tube
16 3 Assembly screws
17 Baseplate
18 Angle scaling
19 Retaining screw for drilling
bench
Inclination (not visible)
20 Drilling bench
21 Vice
22 Chuck jaws
23 Vice mounting material
24 Locking handle
25 Motor side drive pulley
26 V-belt
27 Interlock switch
28 Spindle-side drive pulley
29 Drill chuck key
30 Allen key
Technical Data
Bench Drill PTBM 500 A1:
Rated input voltage
......................................230 V~, 50 Hz
Power input ............ 500 W (S2 15 min)*
Idling speed (n
0
) ......................1400 min -1
Safety class .......................................... I
Protection category......................... IP 20
Weight ........................................ 14 kg
Drill chuck .....................3 mm bis 16 mm
Spindle stroke ..............................50 mm
Spindle speed ................500 - 2500 min -1
Sound pressure level
(L
pA
) ...............74,5 dB(A); K
pA
= 3 dB(A)
Sound power level (L
wA
)
measured .......85,6 dB(A); K
wA
= 3 dB(A)
guaranteed .......89 dB(A); K
wA
= 3 dB(A)
Vibration(a
h
)
........................... 2,39 m/s 2 K= 1,5 m/s 2
