11 GB/IE
Operation
= cloudburst /
storm
= rainy
j Press the HISTORY / WEATHER button 27 to
confirm your settings.
note: Ensure that you have set the current
weather correctly, otherwise the weather
forecast will not be correctly displayed.
j The weather station starts with the weather
forecast approximately 6 hours after you
enter the current weather.
j The weather station can display the barometric
pressure trend 25 . You may see the following
displays:
= the barometric pressure will rise.
= the barometric pressure will remain
constant.
= the barometric pressure will fall.
Q
Reading the barometric
pressure
j Press the Relative / absolute barometric pres-
sure button 30 to switch between the relative
and absolute barometric pressure display.
note: The display shows “Abs” if you have
selected absolute pressure. The display shows
“Rel” if you have selected relative pressure.
note: The absolute barometric pressure is
measured by the weather station.
j Set the relative barometric pressure to the
barometric pressure relative to that at sea
level. Ask your local weather forecast service
for the barometric pressure at sea level.
j Press and hold down the Relative / absolute
barometric pressure button 30 for about
3 seconds.
j Set the current barometric pressure by press-
ing the “+“ / °C / °F button 28 or the
“–“ / MAX / MIN button 29 .
j Press the Relative / absolute barometric
pressure button 30 to confirm your settings.
Q  Reading the barometric
pressure for the last 12 hours
j Press the HISTORY / WEATHER button 27
to read the barometric pressure values for
the last 12 hours.
0HR = present barometric pressure
– 1HR = barometric pressure an hour earlier
– 2HR = barometric pressure two hours
earlier, etc.
j Press and hold down the “+“ / °C / °F button
28 for about 3 seconds to switch between
displaying the barometric pressure units in
inHg or mb / hPa.
Q  Setting the channel
The weather station receives the sensor signal
automatically after you have made all the settings.
The field for the Outdoor temperature
24 flashes
during this time.
note: If you use more than one sensor (max. 3),
you can receive the data from each of the outdoor
sensors separately.
j Set a different channel for each of the sensors.
j To do this open the battery compartment on
the back of the outdoor sensor and take it off.
j Set the channel by means of the Channel
selection switch 39 .
j Press the TX button 42 to transmit the measured
temperature to the weather station manually.
The latter sounds an audible signal when it
receives the signal.
j Then close the battery compartment 40 .
Q  Displaying the outdoor
temperature
j Press the Channel button 26 to display the
outdoor temperature of each outdoor sensor.
- Press the Channel button 26 1 x to display
channel 1.
- Press the Channel button 26 2 x to display
channel 2.
- Press the Channel button 26 3 x to display
channel 3.
- Press the Channel button 26 4 x to display
all the channels one after the other in a loop.
j Press and hold down the Channel button 26
to remove unused channels. If a further out-
door sensor and channel are added later,
the weather station will receive the signal
automatically. Alternatively, you can also
transmit the initial signal from the outdoor
sensor manually by pressing the TX button
42 .
Q
Displaying the temperature
trend (outdoor)
After successfully connecting with the outdoor
sensor, the weather station can display the
Temperature trend
21 .
You may see the following displays:
= The outdoor temperature is rising.
= The outdoor temperature is remaining
constant.
= The outdoor temperature is falling.
