Auriol Z29536 - Handbuch (Seite 12)

12 GB/IE
Operation / Troubleshooting
Q
Displaying the indoor
temperature
The current Indoor temperature 3 is shown in
the LC display.
Q
Displaying temperatures
in °C / °F
note: °C is the legally required temperature unit.
note: The weather station is supplied in the
default setting of °Celsius.
j Press the “+“ / °C / °F button 28 to switch
between the Celsius and Fahrenheit tempera-
ture scales.
Q
Displaying the air humidity
(indoor)
The current air humidity 5 is shown in the LC
display. The Comfort indicator 4 displays the
air humidity in three categories.
The following categories are available:
“Dry” = Air humidity 5 < 45 %
“Comfort” = Air humidity 5 45 - 75 %,
indoor temperature 3
24 °C - 27.9 °C
“Wet” = Air humidity 5 > 75 %
Q
Displaying the Maximum /
Minimum Temperature /
Humidity
The minimum / maximum temperature / humidity is
measured for the first time after the batteries have
been inserted and stored in the weather station.
j Press the “–“ / MAX / MIN button 29 briefly.
The maximum indoor 3 and outdoor tem-
perature 24 measured and the maximum
humidity 5 measured are shown.
j Press the “–“ / MAX / MIN button 29 again
briefly. The minimum indoor 3 and outdoor
temperature 24 measured and the minimum
humidity 5 measured are shown.
j Press the “–“ / MAX / MIN button 29 again
briefly to return to the current values.
note: If no button is pressed within 5 seconds,
the displays automatically return to the
standard display.
j Hold the “–“ / MAX / MIN button 29 down
for approx. 3 seconds in order to delete the
stored maximum and minimum values when
you hear a beep sound. The values measured
from the time of deletion of the old values
until the next time the memory is called up
can be called up again.
Q
Backlight
j Press the SNOOZE / LIGHT button 12 . The
backlight illuminates for 3 seconds.
Q  Battery state display
The Battery state indicator 23 appears in the
weather station’s LC display if the batteries are
weak. Make sure you replace the batteries at the
earliest opportunity (see “Replacing the batteries”).
Q
Replacing the batteries
Weather station:
You should replace the batteries if the display
becomes unclear.
j Remove the battery compartment cover on
the back of the weather station.
j Remove the used batteries.
j Insert 3 new batteries type AA 1.5 V
(Mignon, LR06).
note: Make sure you fit the batteries the
right way round (polarity). The correct polarity
is shown inside the battery compartment
34 .
j Close the battery compartment 34 .
j Press the RESET button 33 . All the symbols
light up briefly.
Outdoor sensor:
note: For this step you need a flat-blade
screwdriver.
j Open the battery compartment cover on the
rear of the outdoor sensor by turning the
screw in an anticlockwise direction with the
flat-blade screwdriver.
j Remove the used batteries.
j Insert 2 new batteries of type AAA 1.5 V
(Micro, LR03).
note: Ensure the correct polarity. This is
shown in the battery compartment
40 .
j Close the battery compartment cover and
tighten the screw in a clockwise direction.
Q
Troubleshooting
note: This appliance has delicate electronic
components. This means that if it is placed near
an object that transmits radio signals, it could
cause interference. This could be, for example,
mobile telephones, walkie talkies, CB radios,
remote controls and microwaves.
j If the display indicates a problem, move such
objects away from it or remove the batteries
for a short while and then replace them.
