5 GB/IE
Introduction
Radio-controlled weather station
Q
Introduction
Familiarise yourself with the product
before using it for the first time. In
addition please refer carefully to the
operating instructions below and the safety advice.
Use the product only as described and for the
indicated purpose. Keep these instructions in a
safe place. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation.
Q  Intended Use
The weather station displays the indoor and out-
door temperatures in Celsius (°C) or Fahrenheit
(°F), the indoor air humidity in percent (% RH) and
their maximum and minimum values. The weather
station also displays the weather forecast, the time
in 12 / 24-hour clock modes and the date. The
weather station also displays the sunrise and sunset
times for that day and the phase of the moon.
In addition, the weather station has an alarm and
calendar function. Other uses or changes to the
device are considered to be contrary to the intend-
ed use and may result in personal injury and / or
damage to the device. The manufacturer accepts
no liability for damage caused through the use
of the device in contradiction of its intended use.
The device is not intended for commercial use.
Q  Description of parts
and features
Weather station
1 Weather symbol
2 Barometric pressure bar display
3 Indoor air temperature
4 Comfort indicator
5 Air humidity (%RH) (indoor)
6 Moon phase
7 Moon rise / set
8 Location
9 Sunrise / time of sunrise
10 ALARM button
11 / button
12 SNOOZE / LIGHT button
13 Alarm icon
14 / 12 / 24 button
15 MODE button
16 Date (year, month, day)
17 Time display
18 Radio tower symbol
19 Barometric pressure of previous hour
20 Absolute / relative barometric pressure
21 Temperature trend (outdoor)
22 Selected channel
23 Battery state indicator
24 Outdoor temperature
25 Barometric pressure trend
26 Channel button (CHANNEL)
27 HISTORY / WEATHER button
(Weather data memory)
28 “+“ / °C / °F button
29 “–“ / MAX / MIN button
30 Relative / absolute barometric pressure button
31 SUN / MOON button (Sun / moon)
32 Wall mounting hole
33 Reset button
34 Battery compartment
35 Stand
Sensor
36 Control LED
37 Outdoor temperature / outdoor sensor channel
38 Wall mounting hole
39 Channel selector switch
40 Battery compartment
41 °C / °F button
42 TX button (“Channel setting button”)
43 Stand
Q
Technical Data
Weather Station:
Temperature range:
0 - + 50 °C
+ 32 - + 122 °F
Temperature resolution: 0.1 °C
Humidity
measurement range:
20 % - 99 %
Humidity resolution: 1 %
Radio signal: DCF
Battery: 3 x AA 1.5 V
(Mignon, LR06, included
in scope of supply)
Dimensions: 230 x 150 x 30 mm
(B x H x D)
Outdoor Sensor:
Temperature
measurement range:
– 20 - + 50 °C
– 4 - + 122 °F
HF transmission signal: 433 MHz
HF transmission range: max. 25 Meter
in open spaces
Battery: 2 x AAA 1.5 V
(Micro, LR03, included
in scope of supply)
Q
Scope of Supply
Please check the supplied items immediately
after unpacking the device to ensure that there is
nothing missing and that the product and all of
its parts are in perfect condition.
1 x Weather station
1 x Outdoor sensor
3 x Battery AA 1.5 V (Mignon, LR06, pre-installed)
2 x Dowel
2 x Screw
2 x Battery AAA 1.5 V (Micro, LR03 pre-installed)
1 x Operating instructions
