SNAXO Specifications
7 SNAXO Specifications
SNAXO362BMR SNAXO362 SNAXO242
Input Impedance 20kΩ 13kΩ 20kΩ
Nominal Input Level 775mV 775mV 775mV
Level Adjustment +0db, -5dB +0db, -5dB +0db, -5dB
Filter Frequencies 400Hz, 3rd Order 300Hz, 3rd Order 3kHz, 3rd Order
3kHz, 3rd Order
Outputs 6 x 4 pin DIN 6 x 4 pin DIN 4 x 4 pin DIN
Nominal Output Level 775mV 775mV 775mV
Min Load Impedance 10kΩ 10kΩ 10kΩ
Power Supply Voltage 24V 24V 24V
Power Supply Options FlatCap FlatCap FlatCap
Hi-Cap Hi-Cap Hi-Cap
SuperCap SuperCap SuperCap
Weight 7.25kg 3.20kg 3.20kg
Dimensions (H x W x D) 87 x 207 x 314mm 87 x 207 x 314mm 87 x 207 x 314mm
