7
SNAXO Amplifier Connections
6.3 SNAXO 362BMR connected to 2 x NAP250
cable
direction
marker
(white)
mains input
and fuse
mains input
and fuse
left
speaker BMR
left speaker LF1 &
LF2 via Naim Y-Link
speaker cable splitter
right
speaker BMR
right speaker LF1 & LF2
via Naim Y-Link speaker
cable splitter
Note: The Naim Y-Link speaker cable splitter enables the twin
low frequency drivers of a Naim Ovator S-800 Ovator S-600 and
Ovator S-400 speaker to be driven from one amplifier channel.
Contact your local retailer or distributor for more information.
4 pin DIN to XLR
Interconnect Cables
