BECKHOFF CB4052 - Handbuch (Seite 48)

Kapitel: BIOS-Einstellungen Integrated Peripherals
Seite 48 Beckhoff New Automation Technology CB4052
5.6.1 OnChip IDE Devices
Phoenix – AwardBIOS CMOS Setup Utility
OnChip IDE Device
IDE HDD Block Mode [Enabled]
Item Help
IDE DMA transfer access [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
On-Chip Secondary PCI IDE [Enabled]
IDE Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
IDE Secondary Master UDMA [Auto]
IDE Secondary Slave UDMA [Auto]
SATA Mode [IDE]
LEGACY Mode Support [Disabled]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü IDE HDD Block Mode
Optionen: Enabled / Disabled
ü IDE DMA transfer access
Optionen: Enabled / Disabled
ü IDE Primary Master PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Primary Slave PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Primary Master UDMA
Optionen: Disabled / Auto
ü IDE Primary Slave UDMA
Optionen: Disabled / Auto
ü On-Chip Secondary PCI IDE
Optionen: Enabled / Disabled
ü IDE Secondary Master PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Secondary Slave PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Secondary Master UDMA
Optionen: Disabled / Auto
ü IDE Secondary Slave UDMA
Optionen: Disabled / Auto
