Guntermann & Drunck GmbH Installation and operating manual
for RS232 extenders
Page 8 Version 1.00
 7HFKQLFDOGDWD
 7HFKQLFDOGDWDRQWKH56H[WHQGHU
0D[LPXPGDWDUDWH 115.200 bit/s (57.600bit/s slow mode)
([WHQGHGVLJQDOV full RS232C:
TxD, RxD, RTS, CTS, DTR, DSR, RI, DCD
'LUHFWYROWDJHLVRODWHG up to 50V potential difference between
transmitter and receiver (only signal lines,
shield must be isolated in the cable where
applicable)
2SWLRQ The LQWHUQDO jumper "A" reduces the data rate
to 60% when used ("Slow Mode") which
means that slightly longer cables lengths can
be used. It is essential that the same
configuration is set on ERWK sides in this case!
6XSSO\YROWDJH 5VDC, external power supply unit, minimum of
300 mA, regulated
0D[LPXPSRZHULQWDNH less than 100 mA (per device), conforms to
approx. 0.5W
+RXVLQJ W=55 mm, H=24 mm, L=104 mm
0D[LPXPH[WHQVLRQSDWK depending on cable quality, approx. 200m or
longer
2SHUDWLQJFRQGLWLRQV Operation: 5-45°C,
Rel. air humidity: <80%; non-condensing;
Storage: 10-55°C,
Air humidity: <85%
