Installation and operating manual
for RS232 extenders
Page 9
Version 1.00
0D[LPXPFDEOHOHQJWKV
&DEOHW\SH
6WDQGDUG PRGH PD[
ELWV
6ORZ PRGH PD[
ELWV
AWG26, S-STP, Montrose
Emaxx CBL9646
220M 300M
AWG26, S-STP, ekumaxx 600
flex (violett)
230M 310M
AWG24, UTP, Belden Datatwist 310M
420M
AWG24, FTP, BICC Brand-Rexx
GigaPlus
340M 440M
AWG24, UTP, Lucent/Avaya
Systimax
310M 420M
AWG23, UTP-HF, BICC
Millenium C6U
320M 440M
AWG23, STP, Daetwyler Uninet
7002
340M 440M
AWG22, STP, Daetwyler Uninet
7702
340M 440M
*HQHUDO
PD[LPXP
FDEOH
OHQJWK
UHFRPPHQGDWLRQV
&DEOHW\SH VLPSOLILHG
6WDQGDUG PRGH PD[
ELWV
6ORZ PRGH PD[
ELWV
AWG26 200M
250M
AWG24 260M
340M
AWG23 280M
360M
AWG22 280M
360M
1RWHV
x
Cables with good crosstalk characteristics (less crosstalk) are preferable,
as are cables with shielding.
x
It is essential that cables are a minimum of category 5 (cat.5).
x
The best results are achieved using cable types with AWG24, AWG23 or
AWG22 line strength.
