Main menu
16 · RackConsole 17HR
Vertical Pan
System Settings
OSD Timeout
OSD Horizontal Position
OSD Vertical Position
In this section the Vertical Pan (position of the dis-
play detail) is set. The value entered here
depends on the selected zoom level. The default
vertical pan is 0. When Zoom is set to 0, the posi-
tion of the picture cannot be changed here.
The OSD Timeout is set in this section. The default
value for the timeout is 30 seconds. The value
can be set between 0 and 60 seconds in 5 second
steps. 0 seconds stands for an infinitive value.
The OSD won‘t be switched off when 0 is
selected here.
In this section the Horizontal Position of the OSD is
set. The value can be set between 0 (left margin)
and 100 (right margin). The default value is 0
(center of the Display).
In this section the Vertical Position of the OSD is
set. The value can be set between 0 (left margin)
and 100 (right margin). The default value is 0
(center of the Display).
