Operation in Master-Slave mode:
To set a fixture to slave-mode navigate to REMOTE.
To activate the slave funciton press “ENTER” (keep it down) and press “ESC” in addtion.
The display will show either REMOTE INACTIVE if no DMX-signal is being received or
REMOTE ACTIVE if a DMX-signal is being received.
To leave this fuction press “ESC” (keep it down) and press “ENTER” in addition. Connect
the A8 with DMX cables.
Select STANDALONE/RUN with the master fixture. Start function by pressing “ENTER”
(keep it down) and pressing “ESC” in addition.
All connected fixtures will repeat the steps synchronized to the master fixture.
To leave the menu press “ESC” (keep it down) and press “ENTER” in addition.
If you realize that a fixture reacts inaccurate check if the display shows REMOTE ACTIVE.
Activate the standalone mode:
The standalone mode is activated in the menu STANDALONE, RUN.
To enter the functions press “ENTER” (keep it down) and press “ESC” in addtion.
The A8 will execute sequence in a repeating loop.
To leave press “ESC” and hold it down and press “ENTER” in addition.
With DELETE one step of the sequence can be deleted. Chose the step and confirm the
function with ENTER.
To reset the DMX values of a step use RESET STEP. Select the step and confirm with
“ENTER”. All DMX values of the step will be set on zero.
With CLEAR ALL the complete sequence will be deleted and the display will show
STEP 01/01.
Store cues from a DMX board:
The DMX values can also be programmed by means of a DMX console.
Enter the STANDALONE menu and navigate to CAPT DMX. Programm the DMX-values
with an external DMX-console. To capture the data press „ENTER“. The fixtures display
will show START CAPTURE. To insert, delete or reset use the keys of the control panel
of the fixture.
