5. DMX Protocol
30
channel no. 1 pan
channel no. 2 pan fine
channel no. 3 tilt
channel no. 4 tilt fine
channel no. 5 control
channel no. 6 shutter
channel no. 7 dimmer
channel no. 8 zoom
channel no. 9 pattern
channel no. 10 CTC
channel no. 11 colour wheel
channel no. 12 speed pan/tilt
channel no. 13 speed effects
channel no. 14 blackout move
channel no. 15 red
channel no. 16 green
channel no. 17 blue
channel no. 18 white
STANDARD RGB 8 BIT (S8)
COMPRESSED RGB 8 BIT (C8)
channel no. 1 pan
channel no. 2 pan fine
channel no. 3 tilt
channel no. 4 tilt fine
channel no. 5 control
channel no. 6 shutter
channel no. 7 dimmer
channel no. 8 zoom
channel no. 9 pattern
channel no. 10 CTC
channel no. 11 colour wheel
channel no. 12 red
channel no. 13 green
channel no. 14 blue
channel no. 15 white
channel no. 1 pan
channel no. 2 pan fine
channel no. 3 tilt
channel no. 4 tilt fine
channel no. 5 control
channel no. 6 shutter
channel no. 7 dimmer
channel no. 8 zoom
channel no. 9 pattern
channel no. 10 CTC
channel no. 11 colour wheel
channel no. 12 speed pan/tilt
channel no. 13 speed effects
channel no. 14 blackout move
channel no. 15 red
channel no. 16 red fine
channel no. 17 green
channel no. 18 green fine
channel no. 19 blue
channel no. 20 blue fine
channel no. 21 white
channel no. 22 white fine
STANDARD RGB 16 BIT (S16)
COMPRESSED RGB 16 BIT (C16)
channel no. 1 pan
channel no. 2 pan fine
channel no. 3 tilt
channel no. 4 tilt fine
channel no. 5 control
channel no. 6 shutter
channel no. 7 dimmer
channel no. 8 zoom
channel no. 9 pattern
channel no. 10 CTC
channel no. 11 colour wheel
channel no. 12 red
channel no. 13 red fine
channel no. 14 green
channel no. 15 green fine
channel no. 16 blue
channel no. 17 blue fine
channel no. 18 white
channel no. 19 white fine
The A8 offers 5 different channel modes. In the menu area PERSONALITY, DMX MODE
you can select your mode. The used mode will be displayed in the main menu.
