39
8.Spezifikation / Specifications
Maße, Gewicht / Physical
Länge / Length...........................................................................................359mm (14,13in.)
Breite / Width.............................................................................................265mm (10,43in.)
Höhe / Height.............................................................................................449mm (17,68in.)
Gewicht / Weight.........................................................................................10,5kg (23,1lbs.)
Elektronik / Electrical
Netzanschluß / power connection......................................................100-240VAC, 50-60Hz
Maximale Leistungsaufnahme / Total power consumption..........................................500VA
Durchschnittliche Leistungsaufnahme / average power consumption.........................260VA
Standby power consumption, all effects static, zero light............................................<25VA
Temperatur / Thermal
Maximale Umgebungstemperatur / maximum ambient temperature................40°C (104°F)
Minimale Umgebungstemperatur / minimum ambient temperature......................5°C (41°F)
Optik, Photometrische Daten / Optic, Photometric data
Lichtquelle / Light source................................................................37x RGBW Osram Ostar
Lichtstärke / total luminous power................................................10600 lumen (Zoom max.)
Effekte / Dynamic Effects
Pan...............................................................................................................................433,6°
Tilt................................................................................................................................333,3°
Zoom................................................................4°- 48° (4°- 33° 1/2 peak, 8°- 48° 1/10 peak)
Farbtemperatur / colour temperature......................................CTO, variable 12500K-2500K
Konstruktion / Construction
Farbe / Colour................................................................................................schwarz / black
Gehäuse / Housing....................................................................................................PC ABS
Schutzklasse / IP rating..................................................................................................IP 20
Installation
Aufstellungsort / Location..........................................................Innenraum / Indoor use only
Aufnahme / Mounting.................2x Omega brackets (optional 1x diagonal Omega bracket)
Position / Orientation..............................................................................................jede / any
Mindestabstand zu brennbaren Gegenständen /
Min. distance to combustible materials.........................................................0,5m (39,37 in.)
Anschlüsse / Connections
Netzeingang / AC power input.............................Neutrik PowerCon NAC3MPA (blau / blue)
Netzdurchgang / AC power throughput..............Neutrik PowerCon NAC3MPB (grau / grey)
DMX in / out USITT DMX512.............................................................5-pin, 3-pin in/out XLR
