43
and CTC channel. The colour wheel channel has priority. Only if the colour wheel channel
is set to DMX value 000-001 it is possible to operate the RGBW channels. The glow
RGBW is used for glow effects and can overlay the other colors. The CTC channel can be
combined with both the RGBW channels and the colour wheel channel.
If the effect channels 9-13 are in use, the color wheel channel and main RGBW (depends
on priority) go to background color. Pattern RGBW is foreground color. If priority is on color
wheel channel the effects working with the main RGBW (foreground color).
The control channel (channel 5) offers additional control over the RGBW-channels.
DMX 000-007 : no white balance active.
DMX 008-015 : White balance to 8500K. Marginal reduced intensity of the RGBW strings.
DMX 016-023 : White balance to 6500K. Reduced intensity in blue.Possible reduction in
intensity of green and red. If fixtures are set to this DMX value a white similar to HMI is
achieved.
DMX 024-031: White balance similar to DMX 016-023. Plus the RGBW curves are working
in linear mode so it is possible to use the colour picker function of various lighting control
desks.
The Sparx7 features a colour wheel channel, main RGBW, pattern RGBW, glow RGBW
5.1 color mixing
5.2 User notes
Control channel 5
Some lighting desks have a delay during DMX refreshing and DMX values get missed
during a fade out or using the fader. That means the Sparx7 with his fast reaction time
rate this happen as a shutter and shows flickering in the beam. To avoid this you can
select 5 different modes. Depending on the modus, the reaction time of the Sparx7
gets lower.
Mapping channel 9
the mapping channel split the circular patterns from pattern channel to different LED seg-
ments.
Pattern Mode channel 10
Is an overall channel for mapping, pattern und pattern speed. The pattern mode controls
if a effect is fade, switch, static or a pixel flash. Also a macro area helps fast programming.
Pattern / Pattern speed channel 11/12
This channel provides 7 increasing, decreasing and random patterns and can controlled
by speed and direction with the pattern speed channel. Without mapping channel, the
patterns run in circular form. The pattern mode as overall controls the kind of running.
Color spread channel 13
This channel generates an indexable and rotable color spread on the foreground color of
the running effect.
Sparkle / Sparkle speed channel 14/15
This is the name given channel of the Sparx7. This channel offers a unique sparkling
effect additional with dimmer and zoom channel. The beam is splitted to the ground colors
of the beam depending on the intensity of the channel value. That means full colors get in
sparkling forms to fade in and fade out effects. A mixed color is splitted to the ground
colors.
