46
603R (l/min)
Fördermengen
Schlauch-Nr # 123 26 73 82 184
Schlauch ID mm 4.8 6.4 9.6 12.7 15.9
Schlauch ID " 3/16 1/4 3/8 1/2 5/8
Upm 165 1.5 2.3 4.2 7.4 11
603R (US gpm)
Fördermengen
Schlauch-Nr # 123 26 73 82 184
Schlauch ID mm 4.8 6.4 9.6 12.7 15.9
Schlauch ID " 3/16 1/4 3/8 1/2 5/8
Upm 165 0.4 0.6 1.1 2.0 2.9
603R
Produkt Code
Schlauch ID
mm " # Marprene Bioprene Peroxide Silicone Platinum Silicone
4.8 3/16 123 910.0048.032 913.0048.032
6.4 1/4 26 902.0064.032 903.0064.032 910.0064.032 913.0064.032
9.6 3/8 73 902.0096.032 903.0096.032 910.0096.032 913.0096.032
12.7 1/2 82 902.0127.032 903.0127.032 910.0127.032 913.0127.032
15.9 5/8 184 902.0159.032 903.0159.032 910.0159.032 913.0159.032
Neoprene Butyl Tygon Viton
4.8 3/16 123
6.4 1/4 26 920.0064.032 930.0064.032 950.0064.032 970.0064.032
9.6 3/8 73 920.0096.032 930.0096.032 950.0096.032 970.0096.032
12.7 1/2 82 920.0127.032 930.0127.032 950.0127.032 970.0127.032
15.9 5/8 184 920.0159.032 930.0159.032 950.0159.032 970.0159.032
