Westermo MX-16 - Handbuch (Seite 20)

20 6604-2001
TD
Channel 1
”local” MX-16
RD
Channel 1
”remote” MX-16
Example of data flow trough one pair of MX-16
Transmit condition channel 1 is set to: 10 received characters or 10 ms timeout.
TD
Channel 1
”local” MX-16
RD
Channel 0
”local” MX-16
Example 1
A
A B C D E
B C D E
Header
4 charac-
ters
Data
A B C D E
Data
Timeout
10 ms
RD
Channel 1
”remote” MX-16
RD
Channel 0
”local” MX-16
Example 2
A
A B C D E F G H I J K
A B C D E F G H I J K
B C D E F G H I J K
Header
4 charac-
ters
Header
4 charac-
ters
Data
Single characters
Single characters
Frames
Single characters
Single characters
Frames
