Connection
9 FBC 7 A1
GB
CY
Connecting the appliance
IMPORTANT
This Programmable Water Timer may only be connected to a
drinking water outlet fi tted with a safety device that corresponds
to at least TYPE HD as per EN 1717 (non-return valve with
pipe ventilation).
Appropriate adapters are commercially available. ►
NOTICE
The appliance is equipped with a coupling nut ► 6 for water
taps with a 33.3 mm thread (G1"). The adapter 10 is used to
connect the appliance to water taps with a 26.5 mm thread
(G ³/₄"). Should leaks/spills be encountered when using the
adapter
10 , it is recommended that you wrap the thread of
the tap with Tefl on sealing tape.
For a 26,5 mm thread (G ³⁄₄”): Screw the adapter ♦ 10 onto the
water tap.
Screw the coupling nut ♦ 6 onto the thread of the water tap
resp. the adapter.
Screw the coupling unit ♦ 11 onto the hose connection. You can
the connect a hose to the coupling unit.
Open the water tap. ♦
Connecting the rain sensor
NOTICE
Pay heed to the operating instructions for the rain sensor. ►
Slide the two levers upwards to release the clamps ♦ 7 .
Insert the cable ends of the connection cables into the clamps ♦ 7
then slide the two levers down to lock it again.
