son in order to prevent hazards.
• Do not use the appliance if the on/off
switch does not work properly. Always
have a damaged switch repaired by
our Service Centre (see p. 19).
• Before each use, check the power sup-
ply lead and the extension cable for
damage and ageing. Do not use the
equipment if the cable is damaged or
worn.
Assembly instructions
. Remove.the.power.plug.before.
all.work.on.the.device..Employ.
only.original.parts..Danger.of.
injury.
Unpacking:
Unpack the device and check whether it is
complete:
A
5 Leaf blower motor part
2 Two-part blower/vacuum tube
18 Collection bag with bag holder noz-
zle
22 Flat nozzle
1 Carrying strap
3 + 4 Assembly material
Before putting the device into opera-
tion, the blower / suction tube must
be completely mounted and screwed
tight and the collection bag and car-
rying strap must be attached. The
impeller wheel cover must be closed
and the attachment screws must be
tightened all the way.
Mounting.of.blower./.suction.tube:
Make sure the tubes are held straight
during mounting. The electrical con-
tacts in the tube could be damaged.
B
1. Connect the two parts of the
blower / suction tube (2a + 2b).
The two parts of the tube engage,
whereupon they cannot be disen-
gaged for safety reasons.
2. Fasten down the tube sections us-
ing the smaller enclosed screws
(3).
3. Insert the blower / suction tube
into the blower / suction opening
on the motor component (5). Use
the guide rail on the motor com-
ponent as an aid.
4. Fasten down the tube and motor
component using the larger en-
closed bolts and nuts (4).
Mount.flat.suction.nozzle:
5. To work with the flat suction nozzle
(22), push it onto the suction opening
(23) on the tube until the lateral clips
engage.
To remove the nozzle, pull the clips on
the nozzle apart and pull the nozzle
out of the tube.
Mount.collection.bag:
6. Place the retainer frame (17) onto the
opening on the motor components
(5) so that the grip points towards the
mains cable. Press the retainer frame
over the engagement strip until the cou-
pling lever engages.
Suction operation is only permissible
with the collection bag mounted.
7. Connect the collection bag retainer
loop (19) to the blower / suction tube.
Mount.carrying.strap:
8. Hook the carrying strap (1) onto the at-
tachment bar (8).
