6
GB CY
General description
Overview
See the front fold-out page
for illustrations.
A 1 Carrying strap
2 Two-part blower / suction tube
3 Smaller fastening screws
4 Larger fastening screws
5 Leaf blower motor part
6 Additional grip
7 Quick-release grip fastener
8 Attachment bar for carrying strap
9 On / OFF switch
10 Airstream regulator
11 Casing handle
12 Ventilation openings
13 Allen key
14 Mains cable
15 Cable retainer
16 Operating mode selection switch
17 Collection bag frame
18 Collection bag
19 Retainer loop for collection bag
20 Guide rollers
21 Blower opening
22 Flat suction nozzle with wheels
23 Suction opening
24 Impeller wheel
25 Impeller wheel cover
26 Vibration damper, additional grip
27 Vibration damper, casing grip
Intended purpose
The device is designed only for the blowing
and suction and of dry leaves in private
households and as a hobby device in the
garden. Every other utilization, which is not
explicitly approved in these directions, can
lead to damage to the device and represents
a serious danger to the user.
The device must not be employed in areas
where there is health endangering dusts or
as a wet suction device.
The device is designed for use by adults.
Young people over 16 years may use the
device under supervision only. The use of the
device in the rain or in a humid environment
is forbidden.
The operator or user is responsible for ac-
cidents or damage to other persons or their
property.
The manufacturer is not liable for damage
which is caused through inappropriate use
or incorrect operation.
Function description
The garden vacuum has a blowing/vacuuming
unit for the blowing and suction functions. In
blowing mode, you can quickly blow together
fallen leaves or blown them out of places that
are difficult to reach. In suction mode, the
leaves are shredded to save space, and blown
out of the ejector outlet into the collection bag.
The handles are equipped with vibration
dampers to improve working safety and re-
duce wrist and arm joint fatigue.
The collection bag is fitted with one-sided inner
lining to prevent fine dust and wetness from
penetrating the bag to the outside. This lining is
located on the left-hand side of the bag to pro-
tect your working clothes from soiling.
You can vacuum up dry leaves and leaf parts
on the flat with the flat suction nozzle. The
