15
CY GB IE
Spare Parts/Accessories
Spare parts and accessories can be obtained at
www.grizzly-service.eu
If you do not have internet access, please contact the Service Centre via telephone
(see “Service-Center” page 17). Please have the order number mentioned below ready.
Pos. exploded Description Order No.
drawing
6-9, 117, 118
Front arm, fully assembled 91096602
10-16 Pipe connector 91096586
17-23 Upper pipe Rohr 91096598
49,97,162-165 Connecting strap 91102870
74+75 Handle with screws for adjusting the blade beam 91096590
62, 120+121 Round handle 91096594
64+66 Leg protection 91096595
74-111+124-128 Gearbox unit with safety blade 91096597
74-111 Gearbox unit without safety blade 91096600
151-153 Carbon brush 91102871
Trouble Shooting
Problem Possible cause Fault correction
Device does not start
Mains voltage not on
Check plug socket, cable, line
and plug, where appropriate,
have repaired through electrical
specialist
On/Off switch (13) defective
Repair by Service Centre Worn carbon brushes
Defective motor
Device runs with inter-
ruptions
Power cable is damaged
Check the cable and have it
changed by the Service Centre if
necessary
Internal loose electrical
connection Repair by Service Centre
On/Off switch (13) defective
Blades become hot
Blades (1) are blunt
Have the blades (1) sharpened or
replaced (Service Centre)
Blades (1) are notched
Have the blades (1) checked or
replaced (Service Centre)
Too much friction due to lack
of lubrication
Oil the blades (1)
