6
GB IE CY
Before use, check that the blades
are sharp. Ensure that the blades are
sharpened whenever blunt, in order
to avoid overstressing of the ma-
chine. Damages caused by cutting
with blunt blades are not covered by
the guarantee.
General Description
Extent of delivery
- Long-handled hedge trimmer (two-part)
- Blade protection
- Leg protection
- Shoulder strap
- Round handle
- Allen wrench
- Instruction Manual
See the front fold-out page for
illustrations.
Overview
A
1 Safety blade
2 Gearbox
3 Angular gear
4 Stop lever fixing
5a Stop lever
5b Safety lever
6 Handle for adjusting the blade
beam
7 Front arm
8 Safety button
9 Pivotal centre
10 Round handle
11 Safety slide
12 Deadman switch
13 On/off switch
14 Strain relief
15 Mains cable
16 Shoulder strap
17 Eye (for shoulder strap)
18 Leg protection
19 Blade protection
C 20 Square nuts
21 Screws
22 Assembly block
Function Description
The electric hedge trimmer is driven by an
electronic motor. The equipment is double-
insulated for safety and does not require
earthing.
The hedge trimmer is equipped with a dou-
ble-sided safety cutter bar. When cutting,
the blades move backwards and forwards
in linear motion. The impact protection on
the tip of the cutter bar prevents unpleasant
recoils should the trimmer come into con-
tact with walls, fences and so on.
The unit can only be operated with the
deadman switch depressed, in order to
protect the operator. In addition, the hand
guard protects against branches and
briars.
Please note the following descriptions for
the function of the operating components.
Technical Data
Electrical Hedge Trimmer .........FHL 900 C4
Input voltage rating ...230-240 V~, 50 Hz
Input power ................................900 W
Safety class .................................... II
Degree of protection ........................ IPX0
Weight ....................................... 5,8 kg
Cutting length ........................... 410 mm
Cutting capacity .......................... 20 mm
Acoustic pressure level (L
pA
)
...................... 84,5 dB(A); K
pA
= 3 dB(A)
Sound power level (L
WA
)
measured ........ 95,6 dB(A); K
WA
= 3 dB(A)
guaranteed ............................. 99 dB(A)
Vibration
at the handle ........................2,083 m/s 2
at the round handle ..............3,132 m/s 2 ;
K = 1,5 m/s 2
Noise and vibration values have been
determined according to the standards and
