10 GB/IE
Preparing for use / Use
Q
Preparing for use/Use
Q
Assembly
Note: Have a vessel filled with approx. 800 ml water ready before
you start assembly.
j
Unpack the product and the accessories carefully.
Note: When you are unpacking the components make sure that
you do not unintentionally throw away any of the assembly materials.
j
Place the water container
12
on a flat and even supporting sur-
face near a mains socket (230-240 V ~, 50 Hz).
j
Mount the lamp attachment assembly
1
on to the ornamental
stone
2
. To do this, position the lamp attachment
4
exactly
over the holes for the lamp attachment
3
and fix it firmly in
place by screwing in the screws
5
(see Figure A and “Replacing
the bulb”). Use a PH1 screwdriver to tighten the screws.
j
Fill the water container
12
with water up to the MAX marking (in-
side wall) of the water container
12
.
j
Connect the pump
8
to the connection hose
7
with the con-
nection piece
15
.
j
Increase (MAX) or reduce (MIN) the flow of water issuing from
the ornamental stone
2
by means the +/- slider
14
(Fig. C).
j
Place the base
6
with the attached pump
8
on the water container
12
and guide the lead from the pump
8
through the recess
16
.
j
Decorate the base
6
with the pebbles
13
.
j
Push the pump plug
9
on to the connection plug
10
.
j
Your tabletop fountain is now ready for use.
Q
Switching the tabletop fountain on and off
j
Push the seal
9
on to the connection plug
10
.
j
Insert the adapter
11
into a properly installed mains socket to
