Safety information / Assembly
Make sure that the polarity is correct when you
insert the batteries. This is indicated in the bat-
tery compartment. The batteries can otherwise
explode.
Clean any light dirt deposits on the contacts of
the batteries or on the contacts of the product
with a dry, fluff-free cloth before insertion.
Please do not dispose of used batteries in your
household waste but take them to a designated
collection depot for special waste.
Assembly
Note: Before first use, please remove the protective
foil between the toilet lid and seat.
Remove the hinges
1
from the included pack
and insert them into the connection fittings on
the toilet seat
8
(see Fig. A).
Fit the plastic washers
4
over the threaded
rods of the hinges
1
(see Fig. A).
Place the toilet seat
8
on to the toilet bowl.
Guide the threaded rods of the hinges
1
through the openings at the back of the toilet
bowl (see Fig. B).
You can adjust the position of the toilet seat
8
by moving the threaded rods of the hinges
1
backwards and forwards inside the openings.
Press the fastening caps of the hinges over the
plastic washers
4
to fix the position of the toilet
seat
8
. Now fit the sealing cone washers
2
over the threaded rods of the hinges
1
and
fix them in place with the plastic nuts
5
. Now
fit the metal washers
3
over the threaded
rods of the hinges
1
and fix them in place
with the metal nuts
6
. Use the wings for the
nuts
7
as a tightening aid.
Inserting and replacing
batteries
Before first use, open the battery box
10
using
a Phillips screwdriver (not included).
Insert 2 x 1.5 V
AA batteries (Model
Z30397 A) or 3 x 1.5 V
AA batteries
(Model Z30397B) into the battery box
10
.
Note: Make sure you fit the batteries the right
way round (polarity). The correct orientation is
shown in the battery box
10
.
Close the battery box
10
and fasten it using
the Phillips screwdriver.
Creating the electrical
connection
Remove the silicone cap
9
and put it away in
a safe place.
Insert the plug
12
of the battery box
10
into
the socket on the toilet seat
8
(see Fig. D).
Check that the plug
12
is securely inserted into
the socket.
Open the lid of the toilet seat
8
and press the
ON / OFF switch
13
on the battery box
10
to
switch on the LED light (see Fig. D).
Close the lid of the toilet seat
8
or press the
ON / OFF switch
13
on the battery box
10
again to switch off the LED light.
Note: Leave the ON / OFF switch
13
in the
OFF position if you do not wish to use the LED
function.
Fastening the battery box in
place (see Fig. E)
Pull off the protective foil from the back of the
pile and loop fastening strip
11
and stick the
strip on to the battery box
10
.
Pull the second protective foil from the pile and
loop fastening strip
11
and stick the battery
box
10
in the desired position on the wall or
other surface.
Now you can take the battery box
10
off the
wall at anytime by separating the two parts of
pile and loop fastening strip.
Note: Do not use the product for the first
24 hours after installation to allow the adhesive
on the pile and loop fastening strip
11
to
achieve its full bond strength. Once fixed in
position, do not pull the pile and loop fastening
strip from the supporting surface. The adhesive
foil could lose its ability to stick.
