4 GB/IE
Installation
Installing the tap
Note: To protect the parts from scratches while
being screwed together cover them with a damp
cloth or use plastic clamps.
Before you start installation turn off the main
water supply to prevent serious leakage of water.
Install the tap at the wall connection as shown
in Figure A.
Connecting the accessories (shower head
and shower hose)*:
Note: So that the parts do not get scratched while
being screwed together, protect them with a damp
cloth or use plastic clamps.
Screw an ordinary shower hose* firmly on to
the thread 4b .
Attach an ordinary shower head* to the
shower hose*.
Observe the installation instructions for the
accessories.
* (not included)
Flushing the tap
The tap must be flushed through before first use
to remove any dirt. To do this, follow these steps
(see Fig. B):
Screw the mixer nozzle 5 off.
Before using the tap for the first time, open the
main water supply. and allow the water to run for
two minutes so that any residues are dissolved
away.
Then screw the mixer nozzle on again.
Operation
Bringing into use
Note: If the tap has not been used for a long period
flush the pipes through thoroughly in order to avoid
stagnation and build-up of residues in the drinking
water supply.
Adjusting the flow
Turn the water flow switch 6 to adjust the
water flow.
Increase:
Turn the water flow switch upward.
Reduce:
Turn the water flow switch downward.
Adjusting the water
temperature
Turn the temperature control switch 7 to
adjust the water temperature.
To raise:
Turn the temperature control switch downward.
To lower:
Turn the temperature control switch upward.
Temperature limit
Limiting the water temperature prevents accidentally
setting the water temperature above 38°C. For a
higher water temperature press the push button on
the temperature control knob whilst turning the tem-
perature control knob downward until the desired
temperature is reached.
Eco-stop function
This fitting features Eco-stop function limiting the
water-flow. Press the push button on the water flow
switch
6 whilst turning the water flow switch
upwards to increase the water flow rate.
