25 GB
contents. All connections must therefore be checked carefully to
ensure that they are tight.
Ensure that all seals are correctly seated to avoid escape of water
due to leakage.
Familiarise yourself with all local conditions, e.g. water connections
and shut-off device, prior to installation.
This product is only suitable for use in rooms with temperature
above 0 °C. In case of potential frost, cut off the water supply and
drain the taps.
Assembly
Note: Familiarise yourself with the product prior to assembly. Carefully
read the following assembly instructions and safety advice. In the event
of incorrect installation, all warranty claims – particularly in relation to
subsequent damage – are excluded.
CAUTION! Before you start installation turn off the water supply
at the mains. Otherwise there is a danger of injury and / or dam-
age to the product.
CAUTION! Do not twist or strain the connection hoses 16 .
Note: This step requires a slot screwdriver and a 12 mm open-end
spanner.
Follow these steps:
CAUTION! Be sure to only fasten the connecting hoses 16 hand
tight (see Fig. A). Do not use pliers or a wrench. Otherwise the
product could be damaged.
Screw the two connecting hoses 16 hand tight into the designated
boreholes in the fitting body 8 (see Fig. A).
Using a slot screwdriver tighten the threaded bolt 14 all the way
into the fitting body 8 and remove the fastening nut 15 .
