Kitchen Mixer Tap
Introduction
We congratulate you on the purchase of
your new appliance. You have chosen a
high quality appliance. The assembly
and operating instructions are part of this product.
Before you start the installation please read through
all of these instructions and take note of the advice
they contain. These instructions contain important
information about installation, settings and product
care. Keep these instructions safe and if you pass
on the product to anyone else please pass on the
documentation as well.
This product has been fitted with a non-return valve
to fulfil WRAS requirements.
This product must be connected to the water supply
in accordance with the Water Supply (Water
Fittings) regulations 1999, and must also comply
with UK Building Regulations. If you are in any
doubt about these requirements contact a qualified
plumber, your local Water Company or the Water
Regulations Advisory Service (WRAS).
Intended use
The product is designed only for the regulation of
the hot and cold water flow. It is only intended to
be installed in sink units. This product is suitable for
use with all pressure-resistant hot water systems such
as central heating, continuous-flow water heater,
pressure boiler etc. It is not suitable for low pressure
water heaters such as wood-burning or coal-burning
domestic hot water geysers, oil or gas-fired hot
water geysers, or open electrically heated cylinders.
If in doubt, please consult a plumber or heating
specialist. Any use other than that described here,
or any modification to the product, is not permitted
and may lead to damage to persons or property.
There is also the risk of injury and loss of life. The
product is for private use only and is not intended
for medical or commercial use. The manufacturer
does not accept any liability for any damage
caused by improper use.
Description of parts and
features
1 1 Handle*
2 1 Tap body*
3 1 Rubber washer
4 1 Spray head
5 1 Shower hose
6 1 Sealing ring (tap body)
7 1 Plastic triangle
8 1 C Sealing washer
9 1 C Metal washer
10 2 Long connection hoses
11 2 Union nuts with seal*
12 1 Short connection hose
13 1 Swivel nut*
14 2 Securing nuts
15 2 Threaded bolts
16 1 Locking screw*
17 1 Hot /cold plaque*
18 1 Cartridge covering ring*
19 1 Cartridge retaining ring*
20 1 Cartridge*
21 1 Aerator button
22 1 Shower button
23 1 Aerator*
24 1 Rubber seal (short connection hose)
25 1 Hose weight
26 2 Screws
27 1 Socket head wrench
* preinstalled
Technical data
Connections: G ½“
Shower hose: G ½“, length 120 cm
