General Information and Safety Notes / Assembly and operation Introduction / General Information and Safety Notes
Mixer Shower
Introduction
Congratulations on the purchase of your
new product. You have selected a high
quality product. The assembly and oper-
ating instructions are part of this product. Please care-
fully read these assembly instructions / instructions
for use before use and observe all instructions. These
instructions contain important information about in-
stallation, settings and care. Please retain these in-
stallation instructions / instructions for use and hand
them on to any future owner.
Intended use
The Mixer Shower has been designed for installation
in showers only. All other usages are regarded as
being contrary to the operating instructions and carry
with them a real risk of serious accidents or damage
to property. The Mixer Shower is suitable for use
with continuous flow heaters (if the continuous flow
heater is suitable for operation with mechanically
adjustable mixer taps) and storage water heaters.
This product is not suitable for use with low-pressure
tanks and small-scale tank heaters. This product is
designed to be used for domestic purposes only.
Parts description
1 Shower head rail
2 Seal
3 Shower head
4 Hand shower unit
5 Shower hose
6 Diverter
7 Tub filling / shower mixer valve
8 Handle
9 Diverter tub / shower head
10 Gasket (S-connector)
11 Covering rosette
12 S-connector
13 Shower rail (extendable)
14 Hand shower holder
15 Plastic cover
16 Wall plug
17 Mounting plate
18 Screws (mounting plate)
19 Covering rosette (Shower head rail)
20 Socket screws (shower head rail)
Scope of delivery
1 Mounting plate
2 Screws
2 Wall plugs
2 Socket screws
1 Covering rosette (Shower head rail)
1 Shower head rail
6 Seals
1 Shower head
1 Tub filling / shower mixer valve
2 Covering rosettes (tub filling / shower mixing valve)
2 S-connectors
1 Diverter
1 Shower hose
1 Hand shower unit
1 Hand shower holder
1 Instructions for assembly and use
General Information
and Safety Notes
Safety instructions
Avoid danger from
electric shock!
DANGER TO LIFE!
Seepage or water leaks may result in life-threatening
injuries from electric shock. Carefully check that all
connections are watertight. Additionally, ensure that
all cables from any electrical devices are correctly and
safely installed. Seek specialist advice if necessary.
