10 GB/IE
Error Analysis / Cleaning and Care / Disposal
Start-up / Error Analysis
Turn the control knob SENS
6
in the direction „-” in
order to reduce the sensor range
1
to 5 m.
Turn the control knob SENS
6
in the direction „+”
in order to increase the sensor range
1
.
Setting the light sensitivity (Ill. D)
Turn the control knob LUX
8
in the direction „ “.
The sensor
1
is in the night operation mode and
does not react to light values below 3 Lux.
Turn the control knob LUX
8
in the direction „ “.
The sensor
1
is in the night and day operation mode.
Note: the intermediate range is for various light
values.
Setting the lighting duration
of the device (Ill. D)
Note: the lighting duration of the device can be set from
min. 10 sec. to max 7 min.
Turn the contol knob TIME
7
in the direction „-” in
order to decrease the lighting duration of the device.
Turn the control knob TIME
7
in the direction „+“ in
order to increase the lighting duration of the device.
Note: The lighting duration is always calculated based on
the respective last movement recorded by the sensor
1
.
Error Analysis
Note: The function of the device is dependent on on the
outside temperature. Functional errors may occur due to
strong temperature fluctuations.
Problem
Solution
The connected
lighting does
not illuminate.
a) Check to ensure that the elec-
trical cord and the device are
connected correctly.
b) Replace defective lighting
material.
c) Check the setting of the light
sensitivity.
