Introduction / Safety
Introduction
Motion Sensor
Introduction
Congratulations on the purchase of your new
device. You have selected a high quality prod-
uct. The instructions for use are a part of this
product. They contain important information about safety,
use and disposal. Before using the product please, famil-
iarise yourself with all the operating and safety instruc-
tions. Only use the product as instructed and only for the
specified applications. When passing this product on to
others please be sure to also include all its documentation.
Intended use
The motion detector is intended for the automatic control
of light sources. The product turns on, respectively turns
off sources of light if persons move within the sensor de-
tection area. Other uses or changes to the product consti-
tute improper use and carry serious risks of accidents. The
manufacturer is not liable for any damages due to improper
use. The product is not intended for commercial use.
Technical Data
Type: 10174
Model No.:
ST10A
Rated voltage:
220–240 V∼ 50 Hz
Nominal load:
max. 1200 watt (for light
bulb lighting material)
max. 300 watt (for en-
ergy saving lighting
material)
Protection class:
II /
Delay time min.:
10 sec. - +/- 3 sec.
Delay time max.:
7 min. +/- 2 min.
Surrounding light:
3–2000 Lux (can be set)
Range:
min. 5 m, max. 12 m
(can be set)
Coverage area:
max. 180°
Operating temperature:
-20–40 °C
Operating humidity:
< 93% rF
