Mounting / Start-up
Safety / Mounting
– the motion detector is not installed where there are
strong temperature fluctuations, e.g. due to heating
devices or air conditioners.
Installation
DANGER TO LIFE BY ELECTRIC
SHOCK! Before installation, switch off the electrical
circuit at the circuit breaker box or remove the fuse
from the fuse box.
Note: The recommended installation height is be-
tween 1.8 and 2.5 m.
Note: Before installation, ensure an optimal direc-
tion of motion. The motion detector reacts more sensi-
tively to movement from the side than to motion from
the front (see Ill. A). Therefore, we recommend install-
ing the motion detector
1
to the side of the direc-
tion of movement.
Note: To attach the base plate
4
it is necessary to
drill two holes. We recommend a drill with a 6 mm
diameter.
Remove the screws
2
from the cover of the connec-
tion area by screwing them in the
direction of
rotation (see Ill. B).
Insert the cable through the cable opening
5
of the
base plate
4
.
Screw the base plate
4
to the desired position.
Connect the cable to the screw terminal
3
of the
motion detector as depicted in Ill. C.
Attach the cover of the connection area back to the
base plate
4
by screwing the screws
2
in the
direction of rotation
.
Start-up
Turn the electricity back on. The device is now ready
for use.
Setting the detection range (Ill. D)
Note: the sensor range is max. 12 m (depending on the
surrounding temperature).
